With this LED Motion sensor stair lighting controller, you can easy DIY your own intelligent stair lighting, when you go upstairs, it will light up the lights from downstairs to upstairs,  and if you are going downstairs, it will light up the lights one by one from up to down! Run speed is adjustable, and delay time, you can easy make suitable smart-stair-way to your self!

Features:
PIR sensor stair light controller with daylight sensor.
32 channels constant voltage output drive low voltage LED strip, Max. 1A current per channel.
2 groups SPI(TTL) signal output, drive 27 kinds IC digital RGB LED strip, IC type and R/G/B order can be set.
Compatible ICs: TM1803, TM1804, TM1809, TM1812, UCS1903, UCS1909, UCS1912, UCS2903,
UCS2909, UCS2912, WS2811,WS2812, TM1829, TM1914A, GW6205, GS8206, LPD6803, LPD1101,
D705, UCS6909, UCS6912, LPD8803, LPD8806, WS2801, WS2803, P9813, SK9822.
Easy operation with OLED display and 3 buttons.
four work light mode selectable.
Two stair light controller can cascade.
Built-in multiple color mode, speed 1-8 grade adjustable.
Push switch can also be as induction signal input.
With fast self-testing function.

TECHNICAL DETAILS
Input voltage    5-24VDC
Output voltage    32 x (5-24)VDC
Output current    32CH,1A/CH
Output power    32 x (5-24)W
Output type    Constant voltage + SPI(TTL)
IP rating    IP20
Warranty    5 years
Protection    Revese Polarity
Operating Temperature    -20~+45 °C (-4~+113 °F)
Certification    CE,EMC,LVD

Package Contents:
1 x controller
1 x 30cm daylight sensor
2 x PIR sensors
2 x 5m PIR sensor extension cables

Only the above package content, other products are not included.
Note: Light and different displays may cause the color of the item in the picture a little different from the real thing. The measurement allowed error is +/- 1-3cm.
